Ficha técnicaCamera
Image Sensor:
1/3" Progressive Scan CMOS
Min. Illumination:
Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON)
Slow shutter:
Support
Shutter time:
1/3 s to 1/100, 000 s
Lens:
2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117°
4 mm, horizontal FOV 77°, vertical FOV 42°, diagonal FOV 88°
6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 58°
Lens Mount:
M12
Adjustment Range:
Pan: 0° to 355°, tilt: 0° to 75°
Day& Night:
IR Cut Filter
Wide Dynamic Range:
120 dB
Digital noise reduction:
3D DNR
Compression Standard
Video Compression:
H.265+/H.265/H.264+/H.264/MJPEG
H.264 code profile:
Baseline Profile/Main Profile/High Profile
Video bit rate:
32Kbps~8Mbps
Max. Image Resolution:
2560 × 1440
Frame Rate:
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream:
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement:
BLC, 3D DNR
Image Settings:
Brightness, saturation, contrast, sharpness are adjustable via web browser or client software
BLC:
Support
Day/Night Switch:
Auto, scheduled
Network
Network Storage:
NAS (Support NFS,SMB/CIFS)
Alarm Trigger:
Motion detection, video tampering alarm, illegal login
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
General Function:
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
System Compatibility:
ONVIF (Profile S, Profile G),ISAPI
Interface
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Reset Button:
Yes
General
Operating Conditions:
-30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
Power Supply:
12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption:
12 VDC, 0.4 A, Max: 5 W
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.13 A, Max: 7 W
Impact Protection:
IK10
Weather Proof:
IP67
IR Range:
Up to 30m
Dimensions:
Camera: ? 111 mm × 82.4 mm (? 4.4" × 3.2")
With package: 134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
Weight:
Without –M model:
Camera: approx. 410 g (0.9 lb.)
With package: approx. 610 g (1.3 lb.)
–M model:
Camera: approx. 455 g (1 lb.)
With package: approx. 655 g (1.4 lb.)
